Zodiac Gold Concludes Drilling Program With Strong Final Results, Including 18M At 4.67 G/T Au
Hole ID | Easting (WGS84) | Northing (WGS84) | Elevation (m) | Azimuth | Dip | Depth (m) |
ADD033 | 323452 | 722616 | 65 | 0 | -50 | 161.10 |
ADD034 | 323335 | 722622 | 60 | 12 | -50 | 181.05 |
ADD035 | 323384 | 722586 | 60 | 12 | -65 | 243.70 |
ADD036 | 323530 | 722562 | 50 | 12 | -50 | 150.65 |
ADD037 | 323672 | 722509 | 58 | 12 | -50 | 149.45 |
ADD038 | 323723 | 722434 | 40 | 12 | -50 | 191.04 |
ADD039 | 323592 | 722518 | 56 | 12 | -50 | 121.30 |
Table 2: Significant Intersections – ADD033 to ADD039
Hole ID | From (m) | To (m) | Interval (m) | Average Au (g/t) |
ADD033 | 11.6 | 12.6 | 1 | 0.28 |
ADD033 | 16.9 | 18 | 1.1 | 0.21 |
ADD033 | 34 | 57.9 | 23.9 | 0.83* |
Including | 42 | 46.04 | 4.04 | 2.07 |
Including | 44 | 45 | 1 | 5.96 |
Including | 54.9 | 56.8 | 1.9 | 2.28 |
ADD033 | 68 | 86 | 18 | 4.67* |
Including | 76 | 86 | 10 | 8.3 |
Including | 81 | 82 | 1 | 55.9 |
ADD033 | 97 | 99.19 | 2.19 | 0.45 |
ADD033 | 109.75 | 110.83 | 1.08 | 0.61 |
ADD033 | 122.8 | 123.8 | 1 | 0.25 |
ADD033 | 135 | 136 | 1 | 1.09 |
ADD034 | 44 | 48 | 4 | 0.41 |
ADD034 | 57 | 61 | 4 | 0.22 |
ADD034 | 73.5 | 99 | 25.5 | 1* |
Including | 76.75 | 86 | 9.25 | 2.14 |
Including | 84 | 85 | 1 | 6.62 |
ADD034 | 113 | 115 | 2 | 0.48 |
ADD035 | 75.34 | 92.85 | 17.51 | 0.91* |
ADD035 | 75.34 | 78.92 | 3.58 | 2.46 |
ADD035 | 100 | 101 | 1 | 0.2 |
ADD035 | 106 | 108 | 2 | 0.28 |
ADD035 | 136 | 143.6 | 7.6 | 0.44 |
Including | 136.69 | 137.7 | 1.01 | 1.04 |
ADD036 | 51.8 | 54 | 2.2 | 0.27 |
ADD036 | 69.61 | 81.85 | 12.24 | 0.92* |
Including | 73.33 | 76.7 | 3.37 | 2.3 |
ADD036 | 111.2 | 122 | 10.8 | 1.24* |
Including | 115.95 | 117.2 | 1.25 | 7.67 |
Including | 115.95 | 116.37 | 0.42 | 22.2 |
Including | 120 | 121 | 1 | 2.1 |
ADD037 | 37.95 | 39.1 | 1.15 | 0.21 |
ADD037 | 41.3 | 43.5 | 2.2 | 0.64 |
ADD037 | 49 | 75.38 | 26.38 | 1.08* |
Including | 56.37 | 60 | 3.63 | 3.92 |
Including | 58 | 60 | 2 | 5.83 |
Including | 67 | 70 | 3 | 2.25 |
ADD037 | 102.25 | 103.38 | 1.13 | 0.4 |
ADD037 | 131 | 133.22 | 2.22 | 1.34 |
ADD038 | 30 | 34.99 | 4.99 | 0.27 |
ADD038 | 76.71 | 89.75 | 13.04 | 1.19 |
Including | 83.45 | 88 | 4.55 | 2.02 |
Including | 86 | 87 | 1 | 5.2 |
ADD038 | 134.5 | 138.5 | 4 | 0.32 |
ADD038 | 168 | 171 | 3 | 0.57 |
ADD039 | 62.7 | 63.84 | 1.14 | 0.41 |
ADD039 | 67 | 68 | 1 | 0.22 |
ADD039 | 78 | 95.25 | 17.25 | 0.95* |
Including | 81.2 | 82.35 | 1.15 | 2.7 |
Including | 89 | 93.92 | 4.92 | 2.08 |
ADD039 | 98.4 | 99.5 | 1.1 | 0.3 |
Note that significant intersections have been determined as intervals above 0.2 g/t Au with a minimum length of 1m and a maximum of 2m of consecutive samples below 0.2 g/t Au, except the intervals marked with an asterisk (*). Intervals marked with an asterisk include a mean of 2.24 consecutive meters below 0.2 g/t Au, ranging from 0.65 to 5m. The zones with over 2 consecutive meters below 0.2 g/t Au have been included to demonstrate downhole continuity where geological logging indicates continuity of shearing and sulphide mineralization in prospective host rocks. Intervals are drilled rather than true thicknesses and it is estimated that true thicknesses for the intervals in ADD033 to ADD039 are approximately 70-90% of drilled thickness.
Drilling, Sampling and QA/QC Procedures
The drilling program at Arthington was completed by a Fordia Eider 2000 diamond drill rig with HQ and NQ core diameter. Core recoveries for holes ADD033 to ADD039 were approaching 100% in fresh rock, where the vast majority of mineralization has been intersected. The easting, northing and elevation data shown in Table 1 have been recorded using handheld GPS only and will be surveyed by differential GPS. Note that an initial attempt at hole ADD039 was abandoned at 81.25m due to drilling conditions. The details of the re-drilled ADD039 are shown in Tables 1 and 2.
Drill core was transported a short distance from the drill site to the Company's exploration camp at Arthington. After geological logging, the core was cut along the long axis using a diamond core saw, with half being sampled and half retained. Where the core was too soft for cutting (in the oxide zone), the core was split using a spatula. Core sampling was completed by Zodiac Gold's geological team, supervised by senior company personnel. All samples met the standards for chain of custody without the opportunity for third party access from Zodiac Gold's exploration camp to SGS Liberia in Monrovia for sample preparation (SGS method PRP87). Each sample was analyzed by 50g fire assay with an atomic absorption finish by SGS Ghana (SGS method FAA505). Samples returning a grade over 10 g/t Au were reanalyzed by 50g fire assay with a gravimetric finish (SGS method FAG505). The new results were incorporated into the database for the calculation of the significant intersections reported above.
SGS Ghana is ISO/IEC 17025 accredited for the methods described above. SGS Liberia is not an accredited laboratory but follows standard SGS sample preparation procedures. SGS is independent of Zodiac Gold. In addition to the laboratory's quality control program, a rigorous quality assurance and quality control program is implemented by the Company, including the insertion of blanks, standards and duplicates to ensure reliable assay results. Quality assurance and quality control data are monitored by the Company. Samples that were not acceptable under the Company's QA/QC protocols were re-assayed by SGS and the new results were incorporated into the database for the calculation of the significant intersections reported above.
Qualified Person
Tom Dowrick, Director of Exploration at Zodiac Gold, is a Chartered Geologist of the Geological Society of London and a Qualified Person as defined by NI 43-101. He has reviewed and approved the technical and scientific information provided in this release.
About Zodiac Gold
Zodiac Gold Inc. (TSXV: ZAU) is a West-African gold exploration company focused on its flagship Todi Project situated in Liberia-an underexplored, politically stable, mining friendly jurisdiction hosting several large-scale gold and iron ore deposits. Strategically positioned along the fertile Todi Shear Zone, Zodiac Gold is developing a district-scale gold opportunity with additional iron ore potential, covering a vast 2,316 km2 land package. The Todi gold project has undergone de-risking, showcasing proven gold occurrences at both surface and depth, with five drill-ready targets, of which two have been drilled and high-grade gold intercepts.
