Battery Mineral Resources Provides Ontario Exploration Update
| Category | Quantity (000' t) | Grade | | Metal | ||||
| Cobalt Percent (%) | Silver grams /tonne (g/t) | Co-Eq* Percent (%) | | Cobalt Pounds (lbs) | Silver Ounces (oz) | Co-Eq* Pounds (lbs) | ||
| Indicated** | 34 | 1.47 | 10.28 | 1.50 | | 1,102,000 | 11,260 | 1,124,000 |
| Inferred | 5 | 1.94 | 10.84 | 1.96 | | 214,000 | 1,650 | 216,000 |
| Mineral resources are not mineral reserves and have not demonstrated economic viability. All figures are rounded to reflect the relative accuracy of the estimate. All composites have been capped where appropriate. **Underground mineral resources are reported at a cut-off grade are reported at a cut-off grade of 0.75% Co-Eq. Cut-off grades are based on a price of US$16 per lb of cobalt, US$17 per oz silver, and assumed recoveries of 100% for underground resources. *Cobalt Equivalency cut-off grade and equivalency formula are defined Co-Eq (%) = Co% + Cu% x 0.175 + Ag g/t x 0.002 | ||||||||
| Metal | CoEq | Price US$/lb | Recovery | Unit Value | ||||
| Cobalt | 1 | US$16.00/lb | 100.00% | $352.74/% | ||||
| Silver | 0.002 | US$17.00/oz | 100.00% | US$0.54/g | ||||
| Copper | 0.175 | US$2.80/lb | 100.00% | $61.73/% |
Note: Technical reports filed by the Company under the Company's profile at : "Technical Report on Cobalt Exploration Assets in Canada" dated as of May 26, 2020 with an effective date of March 31, 2020, prepared by SRK Consulting – G Cole PGeo (APGO#1416).
The McAra deposit is centred within an Archean metavolcanic inlier in contact with Huronian basin sedimentary rocks and proximal to a northwest-southeast striking regional structure. At property scale the regional magnetics clearly define six northwest-southeast trending structural corridors as targets (See Figure 3). Ground follow-up and geophysical surveys are required to identify drill targets in areas underlain by favourable geology within the six regional fault corridors.
Figure 3: McAra Property Reduced to Pole Magnetics with Targeted Structural Corridors
To view an enhanced version of this graphic, please visit:
Gowganda
The Gowganda project is located 75 km southwest of Kirkland Lake in the Van Hise, Haultain, Milner, Nicol and Lawson townships that host the historic Gowganda silver-cobalt camp, which produced 60 million ounces ("oz") of silver between 1910 and 1989. The property consists of 626 mining claims encompassing 9,219 hectares (35.6 square miles) situated along the eastern flank of the historic mining camp.
The property straddles the east-west striking RTDZ regional fault, a deep crustal structure extending west through the Shining Tree gold camp. Exploration to date has focussed on two main mineralization types: Archean hosted gold related to syn-tectonic syenite intrusions and related structures as well as high-grade silver-cobalt mineralization associated with five-element veins hosted within Proterozoic rocks of Cobalt Embayment. A surface exploration program of geological mapping, trenching, channel sampling, prospecting, geophysical surveys and geochemical sampling identified two drill targets, the Kilpatrick and Bald Rock silver-cobalt-nickel vein zones, as well as a series of surface prospects for further evaluation.
At Kilpatrick, excavator stripping and detailed mapping identified a steeply dipping north-south striking mineralized vein in bedrock just east of the historic Capital mine shaft. The sampled vein ranged from 1.5m to 3.0m and yielded cobalt results up to 2.74% cobalt. Significant Channel sample results include:
- TR-18-02: 1.65m at 1.37% cobalt TR-18-03: 1.5m at 2.74% cobalt TR-18-06: 3.0m at 1.85% cobalt TR-18-07: 1.5m at 1.43% cobalt
(For a complete listing of trench channel sampling results refer to "Technical Report on Cobalt Exploration Assets in Canada" dated as of May 26, 2020, with an effective date of March 31, 2020, prepared by SRK Consulting.)
A total of nineteen drillholes (1,768 m) were drilled to better define the vertical and lateral extents of the vein zone as well as to test a relatively deep Induced polarization (IP) anomaly south of the Capitol shaft hosted in the upper portion of the Nipissing diabase sill that hosts the silver deposits at Gowganda. The drilling yielded several narrow vein intercepts with a peak value of 2.6% cobalt and anomalous nickel values (See Figure 4). The IP chargeability response was attributed to disseminated pyrite in the diabase.
Significant drillhole downhole intercepts include:
- GKP20018: 0.5m at 2.85% cobalt & 2.85% nickel GKP19001: 0.5m at 2.55% cobalt & 2.90% nickel GKP20016: 0.3m at 1.86% cobalt GKP19014: 1.79m at 0.15% cobalt GKP19010: 1.3m at 0.28% cobalt GKP19013: 0.75m at 0.18% cobalt GKP19002: 2.8m at 0.12% cobalt GKP19012: 1.0m at 0.12% cobalt
(For a complete listing of drilling downhole intercepts refer to "Technical Report on Cobalt Exploration Assets in Canada" dated as of May 26, 2020, with an effective date of March 31, 2020, prepared by SRK Consulting.)
Figure 4: Kilpatrick Zone Drilling Collar Plan
To view an enhanced version of this graphic, please visit:
The Bald Rock area is extensively covered with glaciolacustrine sands, gravels and clays with limited outcrop exposures restricted mainly to isolated scarps bounding stream valleys and scattered elevated outcrop knobs protruding through the overburden. All of the historic workings were sunk within a narrow north-south trending lens of Nipissing diabase that intrudes the local banded siltstone of the Gowganda formation. The Nipissing diabase and sediments are, in turn, intruded by a later northwest striking diabase dyke.
At Bald Rock, initial ground follow-up focussed on the location and evaluation of historic workings known as the LaCarte showing where previously, the outcrop around several blast pits had been stripped and channel sampled which yielded silver assays to 51.6g/t silver and cobalt values over 1% including one channel of 2.05m returning 4.19g/t silver, >0.3% cobalt, and 1.13% copper. Rock sampling by BMR field crews of the stripped outcrop that was channel sampled in 2011 returned assays of 41.30g/t silver ("Ag"), 1.53% cobalt ("Co") and 7.65% copper ("Cu"). Prior to the BMR drilling there was no record or field evidence of any historic diamond drilling.
The 2021-2022 drilling (14 drillholes /1,401.65 m) was designed to test the vertical continuity and strike extent of the known surface mineralization. Drilling adjacent to and under the workings intersected anomalous cobalt values associated with a strong alteration corridor along the faulted basal contact of the Nipissing diabase with the underlying Huronian sediments (See Figure 5). Selected assay results include:
- GBR21001: 3.0m at 0.63% cobalt & 3.61g/t silver GBR21004: 2.5m at 0.28% cobalt & 1.01g/t silver GBR21005: 2.0m at 0.12% cobalt, 6.22g/t silver & 0.17% copper GBR21001: 1.0m at 0.04% cobalt and 0.30% copper GBR21002: 0.70m at 0.05% cobalt, 1.56g/t silver, and 0.11% copper GBR21004: 1.5m at 0.25% cobalt and 2.94g/t silver
Holes GBR22008 to GBR22011 were designed to test the southerly continuity of the alteration and vein zone, but it appears the zone was offset by a cross-fault. The drilling confirmed mineralization extends vertically below and along strike to the south under sand overburden.
The Bald Rock drill results referenced in this news release were previously disclosed in the Company's news releases dated July 21, 2021 and July 29, 2021, which is available under the Company's profile on SEDAR+ at , and were reported in accordance with NI 43-101.
The extent of the mineralization remains open at depth and along strike to the south of the recently drilled area. A detailed ground magnetics survey is being considered to outline the known mineralization as well as strike extensions and fault offsets to better plan follow-up drilling.
Figure 5: Bald Rock Longitudinal Section Looking West
To view an enhanced version of this graphic, please visit:
At Gowganda, property-scale prospecting mapping and sampling identified several rock grab sample results that warrant follow-up (See Figure 6).
- Babs Lake Prospect:
- 6.60% cobalt, 1,675.00g/t silver, 0.79% copper & 1.96% nickel. 2.47% cobalt, 13.95g/t silver, 0.79% copper & 1.96% nickel.
- 6.04% cobalt, 83.20g/t silver, 0.60% copper & 2.89% nickel. 5.89% cobalt, 6.99g/t silver, 0.04% copper & 1.12% nickel. 5.54% cobalt, 39.40g/t silver, 0.01% copper & 2.31% nickel. 0.08% cobalt, 129.40g/t silver, 3.14% copper & 0.13% nickel.
- 3.83% cobalt, 8.18g/t silver & 0.28% nickel.
- 1.43% cobalt, 7.63g/t silver, 0.59% copper & 0.20% nickel. 1.06% cobalt, 4.98g/t silver, 0.14% copper & 0.39% nickel.
- 1.09% cobalt, 102.00g/t silver, 0.27% copper & 0.17% nickel.
Figure 6: Gowganda Property Targets for Follow-up
To view an enhanced version of this graphic, please visit:
The Gowganda reconnaissance rock sample results referenced in this news release were previously disclosed in the Company's news release dated July 19, 2021, which is available under the Company's profile on SEDAR+ at and were reported in accordance with NI 43-101.
BMR cautions investors that reconnaissance grab samples are selective by their nature and may not necessarily be indicative of similar mineralization at each of targets sampled during the Gowganda reconnaissance program.
Shining Tree
The Shining Tree holdings comprise 143 claims encompassing 2,615 ha (10.1 square miles) in Leonard and Tyrrell townships. The project area is about 12 km southwest of Gowganda and about 17 km east of Shining Tree village.
The Shining Tree project is located within a regional scale fault system that is spatially associated with the nearby Juby gold deposit and the gold deposits in the Swayze greenstone belt, notably the Côté gold deposit both located to the west of the project area.
At Shining Tree, BMR undertook airborne magnetics and radiometric surveys in 2017 along with a LiDAR topography survey in 2018. The airborne magnetics survey clearly defines the Nipissing diabase while the LiDAR data pinpoints the historic workings and surficial work (See Figure 7).
To date, BMR's exploration focused on the Shining Tree central area historic silver-cobalt occurrences. Activities included prospecting, rock grab sampling, geological mapping, induced polarization ("IP") geophysical surveys, mechanical stripping and channel sampling in the Caswell-Eplett shaft area. A first-pass, 10 drillholes / 1,875 m program targeted interpreted IP and resistivity anomalies and tested the known historic outcropping mineralization along strike and at depth. Most of the exploration has targeted silver-cobalt vein mineralization. Target generation for gold as well as additional silver-cobalt veins is required, to be followed by field assessments of the highest ranked targets.
Figure 7: Shining Tree Claims (In Red) Property Targets for Follow-up
To view an enhanced version of this graphic, please visit:
Wilder
The Wilder project is comprised of 130 claims (2,789 ha / 10.8 square miles) in Brewster, Charters, Corkill, Donovan, Leith, Ray, Tretheway, and Milner townships, located between 10 and 30 km south and southeast of Gowganda, Ontario. The Wilder project comprises a Nipissing gabbro sill that hosts a past producing mine and numerous five-element vein style mineral occurrences that contain anomalous silver-cobalt.
BMR's exploration effort to date includes an airborne magnetics and radiometrics survey, a LiDAR topography survey and two grid-based geophysical induced polarization surveys followed by geological mapping, rock sampling and prospecting work (See Figure 8).
Wilder geology comprises variably exposed Huronian Supergroup metasediments and Nipissing diabase intrusions. Huronian rocks in the project area belong to the Gowganda and overlying Lorrain formations. The size and geometry of this Nipissing diabase sill are like ore-hosting sills at the established historic Cobalt and Gowganda mining camps. The target area has "Nipissing Basin" geometry-like the historic Cobalt camp. In the central portion of the Wilder property the Nipissíng diabase hosts five cobalt showings in 5 km long north-south faulted block adjacent to a prominent airborne magnetic low and a radiometric high. Wilder is prospective for contact-style McAra style silver-cobalt mineralization with much of the Nipissing-Huronian contact untested by drillholes.
Wilder is considered by BMR to have potential to host high-grade five-element vein style mineralization because of its regional structural setting and metal endowment. Much of the project area is covered by a relatively thin layer of sand and glacial till with limited outcrop which has made traditional prospecting techniques ineffective. However, this provides an opportunity to deploy modern tools such as geophysical techniques as an aid to targeting in this underexplored area.
Figure 8: Wilder Property Targets for Follow-up
To view an enhanced version of this graphic, please visit:
Quality Control
Sample preparation, analysis and security procedures applied on the BMR exploration projects are aligned with industry best practice. BMR has implemented protocols and procedures to ensure high-quality collection and management of samples, resulting in reliable exploration assay data. BMR has implemented formal analytical quality control monitoring for all of its field sampling and drilling programs by inserting blanks and certified reference materials into every sample sequence dispatched.
Sample preparation was performed by ALS Minerals Laboratories ("ALS") in Sudbury, Ontario and sample analyses by ALS in North Vancouver, British Columbia. ALS analytical facilities are commercial laboratories and are independent from BMR. All BMR samples were bagged and delivered by BMR staff. Upon receipt at the ALS Laboratory in Sudbury, samples were logged in a sophisticated laboratory information management system (LIMS) for sample tracking, scheduling, quality control, and electronic reporting. Samples were dried in special drying ovens prior to crushing. The samples were crushed to 70% < -2 mm, and a riffle split of 250 grams was then pulverized to 85% of the material achieving a size of <75 microns. These prepared samples were then shipped to the ALS Laboratory in North Vancouver for analyses by the following methods:
- ME-MS61: A high precision, multi-acid digest including hydrofluoric, nitric, perchloric and hydrochloric acids. Analysed by inductively coupled plasma ("ICP") mass spectrometry that produced results for 48 elements. ME-OG62: Aqua-Regia digest: Analysed by ICP-Atomic Emission Spectrometry ("AES") or sometimes called optical emission spectrometry ("ICP-OES") for high levels of Co, Cu, nickel ("Ni") and Ag. Ag-GRA21: Silver by fire assay and gravimetric finish; 30-gram charge. Weight. Used when samples contain > 1500 ppm silver. Au-AA25: Gold was analysed by a 30-gram fire assay method, followed by AAS (atomic absorption spectroscopy).
Note that 48 element ICP trace element data was also collected and reported by the laboratory. Certified international standards were inserted into sample batches by ALS. Blanks and duplicates are inserted within each analytical run. The blank is inserted at the beginning, internationally certified standards are inserted at random intervals, and duplicates are analysed at the end of the batch.
Qualified Persons
P. J. Doyle, FAusIMM (#208850), Vice President Exploration of the Company, is a Qualified Person as defined by NI 43-101 and has supervised the preparation of and approved the scientific and technical information in this press release pertaining to the Canada Exploration Program. Mr. Doyle has reviewed and verified the data disclosed herein, including sampling, analytical and test data underlying the scientific and technical data.
Scientific and technical information pertaining to the McAra Resource Estimate was prepared by SRK Consulting (Canada) Inc., under the supervision of G Cole PGeo (APGO#1416).
Technical reports filed by the Company under the Company's profile at : "Technical Report on Cobalt Exploration Assets in Canada" dated as of May 26, 2020 with an effective date of March 31, 2020, prepared by SRK Consulting – G Cole PGeo (APGO#1416).
