Sharing Step By Step Process For The Operation Of Siboasi Soccer Ball Launcher: F2101 & F2101A & F6526

A. Open the packing wooden case:

• Unpack it and take a look
• We must be careful when opening wooden case
• Find the side with the label for disassembly
• First, observe that
• Our current cases utilize a highly convenient design
• It can be directly disassembled without crowbars
• Proceed by lifting upward
• To identify the labeled side, then pry open this panel
• After removing the case
• Release the wheel brakes
• Grip the handle firmly with both hands, lift upward, and pull,to extract the machine.

B. Remove the protective film

• There is a trick for protective film, we must find the source first.
• After film removal, the football machine displays an excellent appearance.

C. Take the tools packing box out:

• Some accessories in the box
• Open it
• We can see remote control,
• Compliance certificate, warranty card, manual,
• Spare fuse,
• Remote batteries, and power cord inside..
• Beside, battery is optional–if do not have it, could use electric power directly
• To play football more easy and convenient.

D. Now let's pull our equipment onto the court to experience it.

• This smart football training machine utilizes twin-wheel extrusion high-speed ball projection technology.
• It launches balls to any field position
• To achieve high-speed serve,
• Our machine unit weighs 102kg
• Despite the weight, it is still very easy to move.
• We can see it has an ergonomic handle, swivel wheels, and a large main wheel.
• Let's note the spiral ball channel,
• Its coiled structure, is both stylish and functional
• Besides, it has 15balls big capacity

E. Now let's load balls into the channel

• We can see the side and rear of the device, this is a control panel
• Here are speed, angle, and frequency adjustment
• Power socket & main switch is below
• Connect power, activate the switch,to start the system.
• It can be controlled by the control panel, remote control,even mobile APP and Watch.

F: Suitable for ball size #4 and #5 ball:

• F2101 and F2101 are for #5 only
• F6526 is for both #4 and#5
• Calibration marks:
• ▮▮ = Size 4
• ▮ = Size 5

G. Operating the remote control for the soccer ball equipment:

• “O” = Factory default (recommended).
• Let's experience this training equipment by remote first
• Long-press power to start: press“F” to enter fixed point mode, then adjust direction button:control serve angle
• Press speed +/-:control serve distance
• Total 9 levels:Value higher, distance farther
• Press frequency +/-: control serve frequency
• Total 9 levels: Value higher, serve ball faster
• Click Topspin +/-:Launches balls with spin-curved trajectory
• Total 9 levels:Value higher, rotation angle bigger
• Let's try vertical serve mode: Press vertical cycle button
• Click start:can train vertical drills:2/3/5 point options
• Click horizontal cycle button: can train horizontal drills:2/3/5 point options
• Click cross-line button:can train cross-line drills
• Click random ball button:can train all-court random drills
• Rigorously tests athletes' reaction capability improve player's football skills quickly
• Finally, let's try programming mode
• Long press Random button to enter“programming mode”: Can set custom serve ball drop location
• Press quantity +/-: Can set serve multiple balls at the same drop location

H. App control

• This equipment can be controlled via mobile phone–F2101A and F6526 has App control, F2101 does not have App
• By scan QR code: behind our user manual
• Download APP
• Open APP
• Connect via Bluetooth
• Once connected, operate the device remotely
• APP mirrors all remote functions and the app interface is more intuitive
• Meanwhile,it can be controlled by smart Watch too–Only F6526 has Watch control.
• Open the Watch:enter the Watch's function interface firstly
• Find APP:Click
• Then click on device control
• Connect via Bluetooth
• Once connected, operate the device freely.

That's all for the steps to operating siboasi soccer ball shooting machines.
